Elevated Bleachers

Elevated Bleachers

$8,235.00$25,984.00

Dimensions: 14′ 6″D x 15’W (5 row 15′ model)
Seats Capacity: 50 (5 row 15′ model)
Weight: 1,500 lbs. (5 row 15′ model)

Lead Time:

1-3 weeks

Clear selection
View Detail
SKU: 36-EL-ADC-A Categories: , Tag: Brands: .


Product Description

Our Elevated Bleachers give spectators the ultimate viewing experience, available in 5, 8, and 10 row configurations.   This bleacher series features 10″ seat planks with a 30″ elevation above finished grade. ADA options can be easily integrated into any size arrangement.

Bleachers are available in either aluminum or galvanized steel. Optional picket-style guardrail available, please call for a quote.

Standard Specs:

  • 8″ Rise/24″ Tread
  • 10″ Seat Plank
  • 17″ Front Row Seat Height
  • Aluminum Frame
  • Double Footboards and Risers
  • 30″ Elevated Above Finished Grade
  • Chain Link Guardrail
  • Aisles with Handrail
  • Accessed via stairs and ramps

Additional Options:

  • Galvanized Frame
  • Aluminum or Galvanized Picket Picket
  • Mud Sills (Wood Sleepers)
  • ADA
Bleacher SizeDimensionsCapacityWeight
5 Row 15’L14′ 6″D x 15’W501,500 lbs.
5 Row 21’L14′ 6″D x 21’W582,000 lbs.
5 Row 27’L14′ 6″D x 27’W782,600 lbs.
5 Row 33’L14′ 6″D x 33’W983,150 lbs.
8 Row 15’L20′ 6″D x 15’W802,240 lbs.
8 Row 21’L20′ 6″D x 21’W913,136 lbs.
8 Row 27’L20′ 6″D x 27’W1234,030 lbs.
8 Row 33’L20′ 6″D x 33’W1594,928 lbs.
10 Row 21’L24′ 6″D x 21’W1132,920 lbs.
10 Row 27’L24′ 6″D x 27’W1535,040 lbs.
10 Row 33’L24′ 6″D x 33’W1936,160 lbs.
Share this page:
Share on FacebookTweet about this on TwitterShare on Google+Pin on PinterestShare on LinkedInEmail this to someone

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Please Note: If your item is listed as “Custom Shipping“, shipping will be charged separately. If you have placed an order via our shopping cart service, you will be contacted with a custom shipping quote before your card is charged for the product cost. Freight shipping cost is determined by delivery address. Additional charges may be incurred for delivery to churches or residential areas as well as any additional services requested.

For more information, please visit our Shipping Info page.

If you would like to obtain a shipping quote or place an order: please contact one of our friendly representatives at 877-857-2915 or email customer service at [email protected].

Share this page:
Share on FacebookTweet about this on TwitterShare on Google+Pin on PinterestShare on LinkedInEmail this to someone

Warranty:
TerraBound Solutions warrants to the owner that this product shall be free from defects in material and workmanship under normal use for a period of one (1) year, provided they are installed per provided installation instructions and that component parts supplied are used.

TerraBound Solutions’ obligation under this warranty shall be limited to repair and exchange of any such item, which may prove defective under normal use (vandalism and premeditated damage excluded) during such period. Warranty period begins at final acceptance by owner.

Freight/Shipping Claims:
Damages and shortages must be identified upon product delivery with freight driver. A customer and freight carrier signed copy of the delivery report should be faxed to the sales support team immediately.
